  6. ACCUD 334-019-01 MICROMETER 35-50mm V-ANVIL 3 flute 60° (0.01mm)
Obrázek produktu ACCUD 334-019-01 MICROMETER 35-50mm V-ANVIL 3 flute 60° (0.01mm)
Obrázek produktu ACCUD 334-019-01 MICROMETER 35-50mm V-ANVIL 3 flute 60° (0.01mm) 1 Obrázek produktu ACCUD 334-019-01 MICROMETER 35-50mm V-ANVIL 3 flute 60° (0.01mm) 2

ACCUD 334-019-01 MICROMETER 35-50mm V-ANVIL 3 flute 60° (0.01mm)

Special analog micrometer for measuring cutting tools with three cutting edges such as taps,… Read more

In stock 0 PCS
At the manufacturer 1 PCS

Order number: 334-019-01

Unable to order, purchase possible after login

Product description

Special analog micrometer for measuring cutting tools with three cutting edges such as taps, milling cutters, reamers, etc.

Technical specification:

  • Range: 35-50mm
  • Accuracy: ±5μm
  • Graduation: 0,01 mm
  • Ratchet stop
  • Carbide measuring faces
  • Supplied with setting standards

Dimensions:

Setting standards:

Measurement scheme:

For more product information, please refer to the attached PDF data sheet below.

Don't know how to choose a suitable meter? Contact our sales representatives! Click HERE to go to the contacts section.

Tato položka je možnost typu INSIZE : 3290-153AThis item is option of INSIZE type : 3290-1This item is option of INSIZE type : 3290-203This item is option of INSIZE type : 3290-503A
