ACCUD HVS1000S DIGITAL MICRO-VICKERS HARDNESS TESTER
NEW!
Basic type digital hardness tester for measuring the hardness of the thin, small workpiece or… Read more
In stock 0 PCS
At the manufacturer 0 PCS
Order number: HVS1000S
Shipping by appointment
Product description
Basic type digital hardness tester for measuring the hardness of the thin, small workpiece or coating. The hardness scale can be changed to Rockwell and Brinell scales.
Technical specification:
- Measuring range: 8-2900HV
- Test load: 0.01, 0.025, 0.05, 0.1, 0.2, 0.3, 0.5, 1kgf
- Unit: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
- Stage elevation: manual
- Loading control: automatic(loading/dwell/unloading)
- Loading time: 1-60s
- Objective: 10X(observation), 40X( measurement)
- Eyepiece: 10X
- Total magnification: 100X(observation), 400X( measurement)
- Max. test height: 100mm
- Max. throat: 110mm
- X-Y stage: size - 100×100mm, travel range - 25×25mm, graduation - 0.01mm
- Dimension: 530×290×490mm
- Weight: 40kg
Included accessories:
- Main unit: 1pc
- 10X eyepiece: 1pc
- X-Ystage: 1pc
- Test block: 1pc
- Level: 1pc
- Dustproof cover: 1pc
- Slice holder: 1pc
- Cylinder holder: 1pc
- Vice: 1pc
Optional accessories:
- Measuring system: HVS-MS
For more product information, please refer to the attached PDF data sheet below.
